Schneider Electric therm.overb.rel.4-6a - LRD10

Aanvullende informatie TeSys LRD thermal overload relay, 6A/690V, thermal setting range 4-6A, tripping class 10A, for protection of 3-phase motors 2.2kW@400V. Differential device with phase failure and load unbalance detection. It provides a thermal adjustement dial, a manual-automatic reset selector, a test selector for simulation of a tripping, reset and stop buttons, a flag indicator and 2 auxiliary contacts 1NO+1NC for fault signalling. Settings are protected by a transparent cover lockable by sealing. Connection by screw clamp terminals, it connects directly to the bottom terminals of 3-pole contactors LC1D09-D38. Mounting on DIN rail or screw fixing, separated from the contactor, with use of a terminal block LAD7B106 (to be ordered separately). Multi standards certified (IEC, UL, CSA, CCC, EAC, ATEX, Marine), Green Premium compliant (RoHs/Reach).

---

TeSys - LRD -Thermisch overbelastingrelais - 6A/690V - Thermisch instelbereik 4-6A - Klasse 10A - Voor bescherming van 3-fasige motoren: 2.2kW@400V. Differentieel apparaat met fasefout (verlies). Hij biedt een thermische afstelschijf, een handmatige automa
