Siemens Sitop psu8200 24 V/40 A - 6EP34378SB000AY0
Artikelnummer: 22351729 | Fabrikantnummer: 6EP34378SB000AY0 | EAN: 4025515154891
Gerelateerde producten:
Bekijk alle gerelateerde producten
Omschrijving
Power supply SITOP PSU8200, 3-phase 24 V DC/40 A
Aanvullende informatie
SITOP PSU8200 24 V/40 A stabilized power supply input: 400-500 V 3 AC output: 24 V DC/40 A *Ex approval no longer available* The SITOP modular 3-phase power supplies are technology power supplies for demanding solutions and provide maximum functionality fo
» Bekijk uitgebreide informatie op de website van Siemens
Specificaties
Klasse |
Gelijkstroomvoedingseenheid
Toon alle producten van deze klasse |
Merk |
Siemens
Toon alle producten van Siemens |
Beschermingsgraad (IP) | IP20 |
Breedte | 135 mm |
Hoogte | 145 mm |
Inbouwbreedte | 135 mm |
Draagrailmontage mogelijk | Ja |
Uitvoering elektrische aansluiting | Schroefaansluiting |
Modulaire uitvoering (voor railmontage) | Ja |
Spanningstype voedingsspanning | AC |
Kortsluitvast | Ja |
Diepte | 150 mm |
Uitgangsspanning geregeld | Ja |
Wandmontage mogelijk | Nee |
Gestabiliseerd | Ja |
Max. uitgangsstroom 1 | 40 A |
Vermogensafgifte | 960 W |
Directe montage mogelijk | Nee |
Secundaire spanning instelbaar | Ja |
Nom. uitgangsspanning 1 | 24 V |
Inbouwhoogte | 225 mm |
Nom. uitgangsstroom 1 | 40 A |
1e Secundaire spanning | 24 - 24 V |
Nom. voedingsspanning bij AC 50 Hz | 400 - 400 V |
Nom. voedingsspanning bij AC 60 Hz | 500 - 500 V |
